【Voltage Compatibility】
When using electrical appliances, please note that they are designed for Japanese voltage specifications (90-110V), so if you use them with a different voltage, it may cause a malfunction.
【Plug Type】
Our products use Japanese plug types (A or B type).
Please use a conversion adapter if necessary.
【Important Note on Transformers and Adapters】
A transformer adjusts voltage to match your device’s requirements.
A conversion adapter only changes the plug shape and does not adjust voltage.
Using only a conversion adapter without a transformer may result in damage to the product.
【Liability】
We are not responsible for malfunctions or damages caused by improper use, such as operating the product without a transformer.
------------------------------------------------------------------------------------------------------------------
Electrical parameter measurement function (voltage, current, active power, energy, frequency, power factor)
Overload alarm function (exceeds power alarm threshold, alarms by backlight and power flashing).
Power alarm threshold preset function (power alarm threshold can be set).
You can reset the energy using the key. Save data when powered off.
Large LCD screen with backlight function. To turn the backlight on or off, press the key briefly. The backlight has a memory function that can save the on or off state when the power is turned off.
Reset Energy Step 1: Press and hold the key for 5 seconds until the energy value starts flashing, then release the key. Step 2: Press the key again briefly to clear the energy value and exit the reset flashing state. Step 3: If no key operation is performed within 5 seconds, the energy value will not be cleared and the reset state will end.
To set the power alarm threshold: Step 1: Press and hold the key until "SET CLr" appears on the LCD screen, then release the key to enter the setting state. Step 2: The power window will display the current power alarm value, and the last digit will begin flashing. If no operation is performed for more than 3 seconds, press the key briefly to the +1 position. The digit position will automatically switch. The setting method is the same as above. Step 3: Once the setting is complete, press and hold the key for more than 5 seconds to automatically save and exit. The active power threshold range is 0.0 to 2.5 kW.
Specifications: 1. Working voltage: 80-260VAC 2. Test voltage: 80-260VAC 3. Rated power: 100A/22000W 4. Working frequency: 45-65Hz
Display format: 1.Power: Test range: 0~22000W, Starting measurement power: 0.2W
