Features:
*High Current Wiring Stud Bus Bar: This power distribution block features four posts and terminal screws, providing a reliable and high current connection point for M8 and M10 wiring studs. It is designed for use in automotive, marine, and RV applications, efficient power distribution.
*Sturdy Construction and Reliable Performance: Made from ABS, zinc alloy, and brass materials, this bus bar is built to withstand the harsh conditions of marine and automotive environments. It can handle a maximum voltage of 48V DC and has a rated current capacity of 62.5A per stud and 250A for the entire electric block.
*Effective Wire Organization: With its compact size of approximately 170*44*33mm, this bus bar helps bring wire harnesses together and neatly store them inside vehicles and boats. It provides a centralized connection point, making wiring installations more organized and efficient.
*Wide Application Range: This bus bar is suitable for various power system applications, including automobiles, RVs, ships, and yachts. It offers a versatile solution for connecting and distributing power in vehicles and boats, reliable and efficient electrical connections.
*Easy Installation and Secure Connection: The 4-post design with terminal screws ensures a secure and stable connection. The bus bar can be easily installed in the desired location, providing a convenient and reliable connection point for wiring installations.
Specifications:
*Part Name:Power Distribution Block
*Material:ABS, Zinc alloy, Brass
*Size:about 170*44*33mm/6.69*1.73*1.30 inch
*Size stud: M8
*Color:Black, Red
*High Universality Fitment:Yes
*Voltage:48V DC
*Current:20A (Auxiliary terminal screw current)
*Rated current of each stud: 62.5A
*Rated current of the entire electric block: 250A
Package Content:
1 x Power Distribution Block
2 x Mounting Screws
Note:
1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness.
2. Please allow slight manual measurement deviation for the data.
