Feature:
1. Adopt for tesla coil principle, output highvoltage pulses, powerful discharge intensity.
2. Compact size, high efficiency, stable and professional performance, dependable to use.
3. The highvoltage modulegenerator made by the circuit composed of components, can be used as a highvoltage source for students" science experimentselectronic instrumentsnegative ion generatorsscience small productions.
4. The input voltage is DC 3.76V and will output DC800KV high voltage.
5. Built to meet standard specification, strictly follow factory quality control.
Specification:
Condition: 100percent Brand New
Item Type: HighVoltage Generator
Material: Plastic
Color: As picture shown
Model: HX901
Length: Approx. 88m3.5in
Diameter: Approx. 26mm1in
Cut Surface Diameter: Approx. 24mm0.9in
Input Voltage: DC3.76V
Output Voltage: DC800KV
Current: Input 4A, output 0.5A
Line Length: Input about 10cm, output about 10 cm
Structure: Integrated housing
Discharge Distance of the Two Poles: Approx. 0.51.5cm (exceeding it will be easily damaged)
Uses: Commonly used in highvoltage production, electronic DIY, product development, highvoltage electronic antitheft, etc.
How to Use: The two poles of the highvoltage output terminal(monochrome thick wire) are fixed within the specified discharge distance, and the lowvoltage input terminal(twocolor thin wire) red wire positive electrode and green wire negative electrode are connected to the battery to produce high voltage arc work.
Input Requirements: This product does not require an auxiliary circuit, and can be used directly by connecting the battery. The input terminal is connected to a single 3.7V lipo battery (such as 18650 battery) or nickelcadmiumnickelhydrogen battery pack, 4V or 6V acid battery, etc. (6V battery can be for best results).
Package List:
1 x HighVoltage Generator
Note:
Precautions for Using the Module:1. The highvoltage module should avoid being energized when the highvoltage is noload. Before powering on, the appropriate distance of the highvoltage line end must be adjusted. The arcing distance of the highvoltage line is proportional to the battery voltage and capacity used.2. Experiment from short to long when testing the arc distance. It is strictly forbidden to exceed the maximum arc distance when energized, because the high voltage energy cannot be released and the module is easily damaged.3. The power of the module is large, and the internal is not suitable for heat dissipation, so it is not allowed to work for a long time.4. The method to judge whether the battery capacity can drive the maximum output power is to measure the battery voltage when the arc is drawn. If it is around 6V, it can output the maximum power.5. The two sections of small capacity lipo batteries are connected in series at 7.2V. The measurement voltage has dropped to about 4V in the arcing state. The smaller the capacity, the lower the voltage. Therefore, it is recommended to use lipo batteries above 2000MA, and it is best to match batteries above 4000MA if possible.Adopt for tesla coil principle, output highvoltage pulses, powerful discharge intensity.
Compact size, high efficiency, stable and professional performance, dependable to use.
The highvoltage modulegenerator made by the circuit composed of components, can be used as a highvoltage source for students" science experimentselectronic instrumentsnegative ion generatorsscience small productions.
The input voltage is DC 3.76V and will output DC800KV high voltage.
Built to meet standard specification, strictly follow factory quality control.
